Schneider Miniature Circuit Breaker C Curve 6Amp 2 Pole

This Acti9 iC60L is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, 6A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 50 kA at 220 Volt AC to 240 Volt AC conforming to EN/IEC 60947-2 standard and 15000 Amp at 400 Volt AC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuit against short circuit and overload current. Its unique VisiTrip indicator reduces intervention time by showing the faulty circuit. Its VisiSafe green strip guarantees the physical opening of the contacts to allow downstream maintenance. Its fast closing mechanism independent of manual operation improves its service life. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500 Volt AC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. It is DIN rail mountable. Its width is 4 pitches of 9 mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 36 mm x (H) 85 mm x (D) 78.5 mm. The weight is 0.25 kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -35 deg C to 70 deg C. The storage temperature is -40 deg C to 85 deg C.
